• Model NO.：MC-852

Basic Info.

Model NO. MC-852

Product Description

Transcranial Magnetic Unique Design Rtms for Brain Dysfunction Rtms

Specifications of Transcranial Magnetic Stimulation:

Transcranial Magnetic Stimulation Encephalopathy Physiotherapy Apparatus

Applicabel for:
Parkinson's Disease,Depression, insomnia,Alzheimer's disease, Obsessive compulsive disorder,Tic disorder,Bipolar disorder, and etc disease for brain.

Advance:

1.Highly effective (based on results of clinical research, rTMS surpasses the success rates of Pharmacotherapy intervention and Electro Convulsive Therapy)

2.Few or no side effects (most severe side effect is a mild headache)

3.Quick onset of therapeutic effect (typically within 1 week)

4.Painless procedure

5.Non-invasive

6.No anesthesia required

7.Excellent ability to target specific neuron circuits

8.Effectiveness only requires 2 to 4 weeks of treatment.

Specification:

1)Instensity: 0-200GS three level adjustable.

2)Frequency: 0-100Hz adjustable

3)Time: 10,20,30min adjustable

4)Power: 220V±10%,50Hz±2%

Treatment:

20~30min per day, Each two weeks one treatment period;Stop one week,then make Next treatment period,Three treatment period are recommend



Operational guidelines for clinical application of therapy apparatus

Disease	Treatment Intensity	Treatment Time	Treatment Frequency	Key Treatment Parts	Massage Choice	Notes
Cerebral arteriosclerosis Insufficient, blood supply to the brain	strong-grade	30 minutes	50Hz	Wear according to the conventional way	Can massage	Can static
Brain atrophy	strong-grade	30 minutes	40-50Hz	Wear according to the conventional way	Can massage	Can static
Alzheimer's disease(AD)	strong-grade	30 minutes	50Hz	Focus on the temporal lobe, parietal lobe	Can massage	Can static
Children with autism	weak-grade, middle-grade	30 minutes	10-30Hz	Focus on the temporal lobe, frontal	Can massage	Can static
Cerebral thrombosis, Cerebral infarction	strong-grade	30 minutes	50Hz	According to CT, MRI lesions parts	Can massage	Can static
Lacunar infarction	strong-grade	30 minutes	50Hz	Wear according to the conventional way	Can massage	Can static
Recovery of traumatic brain injury after operation	strong-grade	30 minutes	30Hz	Wear according to the conventional way	Do not massage
The recovery period after cerebral poisoning	strong-grade	30 minutes	30-50Hz	Wear according to the conventional way	Can massage	Can static
Children with cerebral palsy	weak-grade	20-30 minutes	5-15Hz	Wear according to the conventional way	Can massage	Can static
Parkinson's disease	strong-grade	30 minutes	30-50Hz	Wear according to the conventional way	Can massage	Can static
Depression	strong-grade	20-30 minutes	50Hz	The left side of the treatment body near the left prefrontal treatment	Can massage	Can static
Mental disorders	strong-grade	20-30 minutes	30-50Hz	Wear according to the conventional way Or focus on the frontal	Can massage	Can static
Insomnia	strong-grade	20-30 minutes	5-15Hz	Both sides of the treatment body close to the forehead treatment	Do not massage
Nervous headache	strong-grade	20-30 minutes	20-40Hz	Focus on headache site	Can massage	Can static
High blood pressure	weak-grade	20-30 minutes	5-15Hz	Wear according to the conventional way	Do not massage
Brain fatigue disease	strong-grade	20-30 minutes	30Hz	Wear according to the conventional way	Can massage	Can static
Memory loss	strong-grade	20-30 minutes	30Hz	Wear according to the conventional way	Can massage	Can static
Neurasthenia	middle-grade	20-30 minutes	5-20Hz	Wear according to the conventional way	Can massage	Can static
Schizophrenia	strong-grade	20-30 minutes	5-20Hz	Wear according to the conventional way	Can massage	Can static
