Intelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The Elderly

Nanjing Jin Bai He Medical Apparatus Co., Ltd.
  • Customized：Customized
  • Certification：ISO, CE, FDA
  • Condition：New
  • Tilted：Tilted
  • Folded：Folding
  • Leg Rest Type：Across Both Sides

Base Info

  • Model NO.：D23
  • Material：Aluminium Alloy
  • Type：Electric Wheelchair
  • Unfold Size(Lxwxh)：980X600X970 mm
  • Folded Size(Lxwxh)：330X300X750 mm
  • Battery：Lithium Battery (6ah*2 PCS, DC 24V)
  • Motor：180W * 2 Brushless Motors
  • Load Capacity：120kg
  • Driving Distance：25 Km
  • Max Speed：6km,H
  • Net Weight：23.5kg
  • N.W(Without Battery)：27 Kg
  • Seat Depth：450 mm
  • Seat Width：430 mm
  • Front Wheel：7"X 1.25" Solid PU Tire
  • Rear Wheel：8"X 1.95" Solid PU Tire
  • Standard Color：Black+Blue
  • Brake System：Electromagnetic Brake
  • Transport Package：Standard Export Sea-Worthy Paper Carton
  • Specification：750*450*880mm
  • Trademark：JBH
  • Origin：Jiangsu, China
  • HS Code：8713900000
  • Production Capacity：4000 Sets,Month

Description

Overview MaterialAluminum AlloyUnfolded Dim(LxWxH)Folded Dim(LxWxH)N.W. (Without battery)23.5KGN.W. (With battery)27KGMax Speed6km/hFront Tires7"x1.25" PU solidRear Tires8"x1.95" PU solidArmrests Distance450mmmore suitable for big size peopleRear Seat height520mmFront Seat Height540mmmore comfortable for big size peopleSeat Width430mmSeat Depth450mmPedal High From Ground180mmPacking Carton(LxWxH)430x690x850mmDriving Range25KMLoading Capacity120KGMotor180Wx2pcs blushless motorsControllerDC 24V 2A,100~220VAC,50~60HzLithiun Battery24V 6AHx2/4 pcsClimbing SlopeMax 8°Charging Time6 to 8 hrDrive ModeRear DriveBraking SystemElectromagnetic BrakeWarranty3 months for cushion and tires, 6 months for charger,
1 year for motor, battery and controller, 3 years for frameIntelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The ElderlyIntelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The ElderlyIntelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The ElderlyIntelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The ElderlyIntelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The ElderlyIntelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The ElderlyIntelligent Controller Electric Portable Aluminum D23 Electric Wheelchair for The ElderlyAbout US:FAQ



Q: What does the Wheelchair come with?
A: The Wheelchair comes with two batteries, a charger, a joystick,2 hexagon wrenches,A seat belt  and product manual.
Q: Do I need to take any precautions when charging the Wheelchair ?
A: 1,When charging, If the battery is in built-in wheelchair ,You need ensure that the Wheelchair is Powered OFF

    2,The wheelchair use replacement battery ,which can be carried anywhere to charge,Especially under harsh environmental
conditions outside ,You can take the battery directly to the room for charging. Without having to carry an entire wheelchair

Q: How about Warranty ?
A: First ,We guarantee product quality ,Strictly tested before shipment.

Second ,damage to accessories caused by non-human factors during the warranty period ,We will ship it for free

lithium battery & charger1 year warrantybrushless motor1 year warrantycontroller1 year warrantyAluminum alloy frame2 year warranty

Q: The way your factory cooperates
A: We warmly welcome distributors and end users

For distributors, we provide LOW MOQ ,best price ,privite lable ,drop shipping etc .

For end users, the price will not be lower than the dealer's , however ,group purchase discount .
