Powered by Lithium Battery Electric Wheelchair

Nanjing Jin Bai He Medical Apparatus Co., Ltd.
  • Customized：Non-Customized
  • Certification：ISO, RoHS, CE
  • Condition：New
  • Tilted：Non-Tilted
  • Folded：Folding
  • Leg Rest Type：Across Both Sides

Base Info

  • Model NO.：D09
  • Material：Aluminium Alloy
  • Type：Electric Wheelchair
  • Name：Powered by Lithium Battery Electric Wheelchair
  • Motor：250W*2 PCS Brushless Motor
  • Battery：24V,6ah*2 PCS
  • Wheel：7",12.5" PU Tires
  • Max Loading：120kgs
  • Driving Range：25km
  • Charger：24V2a
  • Charging Time：6-8hours
  • Climbing：8 Deg
  • N.W：25.1kgs
  • G.W：28kgs
  • Over Size：985*600*950mm
  • Flod Size：600*355*790mm
  • Seat Hight：480mm
  • Seat Width：470mm
  • Transport Package：Carton
  • Specification：985*600*950mm
  • Trademark：JBH
  • Origin：Jiangsu, China
  • HS Code：8713100000
  • Production Capacity：3000sets,Month

Description

Model NumberD09TypeElectric WheelchairUnfolded(LxWxH)985x600x950mmFolded600x355x790mmMaterialAerospace AluminumLoad Capacity120kgBattery Capacity24V7AHx2pcsCharge Time6h-8hMaximum Speed6km/hReal Wheels12.5InchesEndurance25kmWheel MaterialPUBrake ModeElectromagnetic BrakeGradeability12Charger TypeLithium BatteryDrive modeRear-wheel DriveN.W:25.1kgsG.W:28kgsPowered by Lithium Battery Electric Wheelchair
Powered by Lithium Battery Electric Wheelchair
Powered by Lithium Battery Electric Wheelchair
Powered by Lithium Battery Electric Wheelchair
FAQ

Q1: How long will be this shipped ?
3 days after your payments confirmed.

Q2: How is the warranty?
    The frame is 3 years.battery.motor,joystick and controller,other parts all is one year.

Q3: Where is the weakest part in wheelchair?
    The weakest part is wheel,but the quality could be guaranteed.

 Q4: How to assemble the wheelchir when i received the wheelchair?
    We have after sales team online 24 hours.

Q5: Can i have some more parts like wheels?
    Yes, but it is not free.
